Product Overview
The SMC ZHV20 is a high vacuum angle seat valve engineered by SMC Corporation, a global leader in pneumatic and vacuum control technology. Designed for precision vacuum isolation and pressure control, this valve operates on a pneumatically actuated piston mechanism that ensures rapid, reliable shut-off in high vacuum circuits. Its robust construction and elastomer sealing technology make it an essential component in industrial vacuum systems, semiconductor manufacturing, and process automation where maintaining vacuum integrity is critical. The ZHV20 is specifically engineered to handle vacuum pressures down to 1.3 x 10-1 Pa while providing leak-tight performance and long service life.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | High Vacuum Valve (Pneumatically Actuated) |
| Model Designation | ZHV20 |
| Operating Pressure | Vacuum service: 1.3 x 10-1 Pa to atmospheric; Pilot air: 0.3–0.7 MPa |
| Mounting & Connection | KF (NW) flange connection, ISO-KF standard |
| Valve Type | Angle seat, normally closed (NC) / normally open (NO) options |
| Body Material | Stainless steel (SUS304 / SUS316) |
| Seal Material | Fluoroelastomer (FKM) / Perfluoroelastomer (FFKM) |
| Port Size | KF-20 (NW20) |
| Actuation | Pneumatic piston actuator, single or double acting |
| Response Time | Fast actuation, typically < 1 second |
| Leak Rate | < 1 x 10-9 Pa·m3/s (helium) |
| Temperature Range | 5°C to 60°C (ambient and media) |
Engineering Features & Advantages
- Precision Performance: The integrated pneumatic piston actuator, single or double acting ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SMC standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
Its robust construction and elastomer sealing technology make it an essential component in industrial vacuum systems, semiconductor manufacturing, and process automation where maintaining vacuum integrity is critical.
PRODUCT IMAGES
SMC ZHV20 High Vacuum Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SMC ZHV20 High-Pressure Coolant Valve. This Japan-made high-pressure hydraulic component features a poppet-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
