Product Overview
The SMC ZK2A10K5ALA-06 is a high-efficiency vacuum ejector unit from the SMC ZK2 series, engineered for precision vacuum generation and workpiece handling in automated industrial systems. Operating on the venturi principle, this pneumatic vacuum ejector converts compressed air into a high-velocity jet that generates a stable vacuum flow through a multi-stage diffuser nozzle. The unit integrates an ejector body, supply valve, and break valve within a compact manifold design, delivering rapid response vacuum generation and release for pick-and-place, packaging, and material handling applications. With a 06 port size and integrated solenoid control, the ZK2A10K5ALA-06 provides reliable, energy-efficient vacuum performance directly compatible with SMC pneumatic circuit architectures.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Process & Pneumatic Valve — Vacuum Ejector Unit |
| Model Designation | ZK2A10K5ALA-06 |
| Manufacturer | SMC Pneumatics |
| Operating Principle | Venturi / Multi-stage Ejector Nozzle |
| Operating Pressure | Standard Industrial Grade (0.2 – 0.6 MPa supply range) |
| Port Size | 06 (6 mm tube connection) |
| Valve Configuration | Integrated Supply & Break Solenoid Valves |
| Mounting & Connection | Standard ISO / SMC Manifold Interface |
Engineering Features & Advantages
- Precision Performance: Multi-stage venturi diffuser design delivers high vacuum flow with minimal air consumption, ensuring rapid evacuation and stable holding force for critical pick-and-place operations.
- Integrated Valve Control: Combined supply and break solenoid valves enable fast vacuum ON/OFF switching, reducing cycle times and improving overall system responsiveness.
- Compact Modular Design: Space-saving ejector body integrates directly into SMC manifold systems, simplifying installation and reducing piping complexity in dense pneumatic circuits.
- Industrial Reliability: Built for continuous operation under severe industrial conditions with robust construction resistant to vibration and repeated cycling.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SMC OEM standards, ensuring drop-in replacement without modification.
Typical Industrial Applications
The SMC ZK2A10K5ALA-06 vacuum ejector unit is widely deployed in automated pick-and-place systems for electronics assembly, packaging machinery for carton and film handling, plastic injection molding machines for part extraction, and CNC machine tool automation for workpiece clamping and transfer. Its rapid response and reliable vacuum generation make it ideal for high-speed material handling, robotic end-effector vacuum gripping, and general factory automation requiring precise pneumatic vacuum control.
PRODUCT IMAGES
SMC ZK2A10K5ALA-06 Vacuum Ejector Unit
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SMC ZK2A10K5ALA-06 Vacuum Ejector Valve. This Japan-made 24VDC pneumatic component features a compact ejector design, delivering leak-free, reliable vacuum control for heavy-duty industrial systems.
