Product Overview
The SMC ZK2A15K5KWA-06 is a high-efficiency vacuum ejector unit from the SMC ZK2 series, engineered for precision vacuum generation and control in pneumatic industrial systems. Utilizing a multi-stage venturi nozzle design, this unit generates vacuum by directing compressed air through a convergent-divergent nozzle, creating a low-pressure zone that draws air from the suction port. The ZK2A15K5KWA-06 integrates an ejector body, supply valve, and break valve into a single compact manifold, delivering rapid response times and stable vacuum pressure for pick-and-place, material handling, and automated assembly operations. As a process and pneumatic valve component, it serves as the central vacuum control interface in SMC pneumatic circuits, offering reliable performance with minimal air consumption.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Process & Pneumatic Valve — Vacuum Ejector Unit |
| Model Designation | ZK2A15K5KWA-06 |
| Operating Pressure | Standard Industrial Grade (0.2 – 0.7 MPa supply air) |
| Mounting & Connection | Standard ISO / SMC manifold interface with push-in fittings |
| Nozzle Diameter | 1.5 mm (multi-stage venturi configuration) |
| Air Consumption | Optimized low-consumption design per SMC ZK2 series standards |
| Valve Function | Integrated supply valve and break valve for vacuum ON/OFF control |
| Port Size | 06 (6 mm tube connection) |
Engineering Features & Advantages
- Precision Vacuum Generation: Multi-stage venturi nozzle delivers high suction flow and deep vacuum levels with minimal compressed air consumption, ensuring efficient pick-and-place performance.
- Integrated Valve Control: Combines supply and break valve functions in a single compact unit, reducing piping complexity and enabling fast vacuum response times for high-cycle automation.
- Industrial Reliability: Built for continuous operation under severe industrial conditions with robust construction and resistance to contamination in pneumatic circuits.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original SMC ZK2 series mounting and port configurations for drop-in installation.
- Compact Modular Design: Space-saving body allows manifold mounting of multiple ejector units, ideal for dense pneumatic control panels.
Typical Industrial Applications
The SMC ZK2A15K5KWA-06 vacuum ejector unit is widely deployed in automated pick-and-place systems for electronics assembly, plastic injection molding machine part removal, packaging and labeling lines, CNC machine tool workpiece clamping, and robotic end-effector vacuum gripping in automotive and general manufacturing environments. Its precise vacuum control and rapid response make it suitable for high-speed material handling where reliable suction and release cycles are critical.</p
PRODUCT IMAGES
SMC ZK2A15K5KWA-06 Vacuum Ejector Unit
