Product Overview
The Spirax Sarco TD16 is a thermodynamic steam trap engineered for high-efficiency condensate removal in steam distribution and process heating systems. Operating on the thermodynamic (disc-type) principle, the TD16 utilizes the dynamic energy of flash steam to cycle a hardened stainless steel disc against a precision-machined seating surface, discharging condensate and non-condensable gases while preventing live steam loss. As a critical component within process and pneumatic valve assemblies, it delivers reliable performance across a broad pressure range, making it a preferred choice for industrial steam mains, tracer lines, and drip points where compact size and robust construction are essential.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Thermodynamic Steam Trap (Process & Pneumatic Valve) |
| Model Designation | Spirax Sarco TD16 |
| Operating Pressure | Up to 16 bar (232 psi) — standard industrial grade |
| Mounting & Connection | Standard ISO threaded or flanged interface (manufacturer specification) |
| Body Material | Stainless steel / hardened alloy internals |
| Seat & Disc | Precision-lapped hardened stainless steel |
| Max. Allowable Temperature | Up to 400°C (752°F) — saturated steam service |
Engineering Features & Advantages
- Precision Performance: Thermodynamic disc actuation provides rapid, cyclic condensate discharge with minimal steam loss, ensuring optimal thermal efficiency in steam systems.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a hardened stainless steel disc and seat resistant to water hammer and superheat.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Spirax Sarco TD16 OEM standards, ensuring drop-in installation without modification.
- Compact & Versatile: Small footprint allows installation in tight spaces; operates effectively across a wide pressure range without adjustment.
- Non-Condensable Gas Discharge: Automatically vents air and other non-condensable gases during start-up and normal operation, preventing system air-binding.
Typical Industrial Applications
The Spirax Sarco TD16 thermodynamic steam trap is widely deployed in heavy industrial scenarios including: steam mains and distribution headers for condensate removal; tracer lines and drip points on process piping; plastic injection molding machines and rubber vulcanization presses requiring precise temperature control; and general process heating systems in chemical, pharmaceutical, and food processing plants. Its robust design also suits marine and offshore steam service where reliability and compactness are critical.
