Product Overview
The SUNFAB SAP-056R-N-DL4-L35-S0S-000 is a high-performance axial piston pump engineered by Sunfab Hydraulics, a globally recognized manufacturer of premium hydraulic components for demanding mobile and industrial applications. This variable displacement axial piston pump utilizes a precision swashplate design, where the angle of the swashplate governs the stroke of the pistons within the rotating cylinder barrel, enabling infinitely variable flow output proportional to the control input. With a nominal displacement of 56 cm³/rev, this pump delivers exceptional volumetric efficiency and high-pressure capability, making it a critical power source in closed and open-loop hydraulic systems. The SAP series is specifically designed for robust continuous duty, offering superior performance in applications requiring precise flow control, high power density, and reliable operation under extreme operating conditions.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Piston Pump (Axial Piston, Variable Displacement) |
| Model Designation | SAP-056R-N-DL4-L35-S0S-000 |
| Nominal Displacement | 56 cm³/rev |
| Operating Pressure | Up to 350 bar continuous / 400 bar peak (standard industrial grade) |
| Maximum Speed | Up to 3,000 rpm (dependent on inlet conditions and fluid viscosity) |
| Control Type | DL4 — Load Sensing / Pressure Compensator Control |
| Mounting & Connection | Standard ISO / SAE flange interface, L35 splined shaft |
| Port Connections | S0S — SAE split flange ports (pressure, suction, drain) |
| Seal Material | NBR (Nitrile) standard; Viton available for high-temperature applications |
| Fluid Compatibility | Mineral-based hydraulic oils, HLP/HM per DIN 51524; viscosity range 10–100 cSt |
Engineering Features & Advantages
- Precision Swashplate Performance: The axial piston design with precision-ground swashplate and cylinder barrel delivers smooth, infinitely variable displacement with minimal pressure ripple and exceptional volumetric efficiency, ensuring precise flow control across the entire operating range.
- Advanced DL4 Load Sensing Control: The integrated DL4 control combines load sensing and pressure compensation, automatically adjusting pump displacement to match system demand. This reduces energy consumption, minimizes heat generation, and extends component life in complex multi-actuator circuits.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Precision-manufactured to original SUNFAB specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
The SAP series is specifically designed for robust continuous duty, offering superior performance in applications requiring precise flow control, high power density, and reliable operation under extreme operating conditions.
PRODUCT IMAGES
SUNFAB SAP-056R-N-DL4-L35-S0S-000 Axial Piston Pump
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine SUNFAB SAP-056R-N-DL4-L35-S0S-000 Solenoid Directional Valve. This Sweden-made 24V DC hydraulic component features a 4-way 3-position design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
