Product Overview
The VAT 26432-KA11-BSP1/0346 is a high-precision vacuum isolation valve engineered by VAT Group, a global leader in vacuum valve technology. Operating on a pneumatically actuated bellows-sealed mechanism, this valve is designed to provide reliable isolation and control of vacuum lines in demanding process environments. Unlike hydraulic directional or pressure control valves, this unit is specifically configured for vacuum service, utilizing a bellows-sealed stem to prevent atmospheric leakage and particulate contamination into the vacuum chamber. Its robust construction ensures leak-tight performance, making it an essential component for semiconductor manufacturing, thin-film deposition, and industrial vacuum coating systems.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Vacuum Isolation Valve (Pneumatic Process Valve) |
| Model Designation | 26432-KA11-BSP1/0346 |
| Operating Pressure | Vacuum Service (High Vacuum to 10-8 mbar range) |
| Mounting & Connection | BSP1 Threaded / Flange Interface (Standard ISO Vacuum Connection) |
| Actuation Method | Pneumatic (Compressed Air Actuated) |
| Sealing Technology | Bellows-Sealed Stem / Elastomer Seal |
Engineering Features & Advantages
- Precision Vacuum Control: The bellows-sealed design ensures zero external leakage and maintains ultra-high vacuum integrity, preventing contamination in critical process chambers.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with a robust pneumatic actuator providing consistent cycle life and rapid response times.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original VAT OEM standards, ensuring seamless integration into existing vacuum systems without modification.
- Contamination-Free Operation: The metal bellows isolates the actuator from the vacuum environment, eliminating particle generation and extending maintenance intervals.
Typical Industrial Applications
This vacuum valve is ideally suited for semiconductor wafer fabrication equipment, physical vapor deposition (PVD) and chemical vapor deposition (CVD) systems, industrial vacuum coating lines, and analytical instrumentation requiring precise vacuum isolation. It is also commonly deployed in freeze-drying and vacuum metallurgy processes where reliable, leak-tight performance is critical.
PRODUCT IMAGES
VAT 26432-KA11-BSP1/0346 Vacuum Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine VAT 26432-KA11-BSP1/0346 Solenoid Directional Control Valve. This Swiss-made hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
