Product Overview
The VERDERAIR VA15PP-PPTFTFTB00 (Part No. 810.6772) is a pneumatically driven Air Operated Double Diaphragm (AODD) pump manufactured by VERDER, engineered for reliable transfer of aggressive, viscous, and shear-sensitive fluids across demanding industrial environments. Operating on a positive displacement, reciprocating diaphragm principle, the pump uses compressed air alternately applied to two flexible diaphragms connected by a common shaft to create a balanced, self-priming pumping action. With a 1/2-inch port size, this model delivers smooth, pulsation-dampened flow without the need for electrical power, making it an ideal solution for hazardous, wet, or remote industrial installations where safety and dependability are paramount.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Air Operated Double Diaphragm Pump (AODD) |
| Model Designation | VERDERAIR VA15PP-PPTFTFTB00 / 810.6772 |
| Port Size | 1/2″ (VA15 Series) |
| Wetted Body Material | Polypropylene (PP) |
| Diaphragm / Valve Material | PTFE (TFT) — Ball Valve Configuration |
| Operating Pressure | Standard Industrial Grade (Up to 8.6 bar / 125 psi air inlet) |
| Mounting & Connection | Standard ISO / Manufacturer Interface (BSP/NPT threaded ports) |
Engineering Features & Advantages
- Precision Performance: Balanced double-diaphragm design delivers smooth, self-priming, and run-dry capable operation with excellent suction lift and consistent flow across varying viscosities.
- Chemical Resistance: Polypropylene body combined with PTFE diaphragms and valve balls provides outstanding compatibility with corrosive acids, caustics, solvents, and aggressive chemical media.
- Industrial Reliability: Built for continuous operation under severe industrial conditions with minimal maintenance, no electrical components, and intrinsically safe pneumatic actuation.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original VERDERAIR OEM standards, ensuring drop-in replacement without system modification.
Typical Industrial Applications
This VERDERAIR VA15PP AODD pump is widely deployed in chemical processing and transfer of aggressive fluids, wastewater and slurry handling, paint and coating circulation, and pharmaceutical or food-grade fluid transfer where shear-sensitive media must be moved gently. Its pneumatic, explosion-proof operation also makes it a preferred choice for hazardous-area and remote industrial installations.
PRODUCT IMAGES
VERDERAIR VA15PP-PPTFTFTB00 / 810.6772 Air Operated Double Diaphragm Pump
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine VERDERAIR VA15PP-PPTFTFTB00 / 810.6772 Air Operated Double Diaphragm Pump. This USA-made pneumatic pump features a non-metallic polypropylene body with PTFE diaphragms, delivering leak-free, reliable fluid transfer for heavy-duty industrial systems.
