Product Overview
The Vickers EPV-16-04-0-10-N-24D-S-W-10 / 02-398882 is a high-performance electro-proportional cartridge valve engineered by Vickers (Eaton) for precise hydraulic flow and pressure control within demanding industrial circuits. Operating on a two-stage proportional solenoid principle, this screw-in cartridge valve modulates spool position proportionally to an electrical input signal, delivering infinitely variable flow metering rather than simple on/off actuation. The EPV series is designed for direct integration into manifold blocks and custom hydraulic integrated circuits (HICs), where its compact cartridge format reduces leakage paths and simplifies system architecture. With a 24V DC solenoid, spring return, and integrated manual override, this valve serves as a critical control element in systems requiring smooth acceleration, deceleration, and load-holding capability.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Electro-Proportional Cartridge Valve (Proportional & Servo Valve) |
| Model Designation | EPV-16-04-0-10-N-24D-S-W-10 / 02-398882 |
| Valve Size / Cavity | Size 16 (CETOP 16 / ISO 4401-16 equivalent cartridge cavity) |
| Actuation Type | Proportional Solenoid, 24V DC, with spring return |
| Operating Pressure | Up to 350 bar (5075 psi) rated working pressure |
| Flow Capacity | Nominal 40 L/min at 10 bar pressure drop (size 04 spool) |
| Spool Configuration | Closed-center, 4-way, 3-position proportional spool |
| Mounting & Connection | Screw-in cartridge, ISO 4401 / CETOP manifold interface |
| Electrical Connector | DIN 43650 / ISO 4400 standard plug with LED indicator |
| Seal Material | NBR (Buna-N) standard; FKM optional for high-temperature service |
| Manual Override | Integrated push-pin manual override for emergency actuation |
Engineering Features & Advantages
- Precision Performance: The electro-proportional cartridge valve (proportional & servo valve) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Vickers OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
- Rated Capability: Rated for pressure ratings up to 350 bar and flow rates up to 40 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
With a 24V DC solenoid, spring return, and integrated manual override, this valve serves as a critical control element in systems requiring smooth acceleration, deceleration, and load-holding capability.
PRODUCT IMAGES
Vickers EPV-16-04-0-10-N-24D-S-W-10 / 02-398882 Electro-Proportional Cartridge Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine Vickers EPV-16-04-0-10-N-24D-S-W-10 / 02-398882 Proportional Directional Valve. This Germany-made 24V DC hydraulic component features a 4-way proportional design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
