Product Overview
The Vickers NV1-10-R-0 (part number 565936) is a precision-engineered cartridge-style needle valve designed for fine manual flow control within industrial hydraulic circuits. Manufactured by Vickers (Eaton), this inline cartridge valve features a tapered needle and matched seat geometry that delivers accurate, repeatable throttling of hydraulic fluid across a broad adjustment range. As a flow control component, the NV1-10-R-0 is typically installed into a machined manifold cavity, where it regulates actuator speed, bleed-off flow, or circuit balancing without the need for external piping. Its robust cartridge construction and fine-thread adjustment stem make it a reliable choice for demanding industrial systems requiring precise, lockable flow settings.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Valve – Cartridge Needle Valve (Flow Control) |
| Model Designation | NV1-10-R-0 / 565936 |
| Manufacturer | Vickers (Eaton) |
| Operating Pressure | Standard Industrial Grade (up to 315 bar rated) |
| Flow Control Method | Manual needle adjustment with tapered metering seat |
| Mounting & Connection | Cartridge-style, manifold cavity mounting per Vickers standard |
| Adjustment Type | Screw-type stem with locknut for setting retention |
Engineering Features & Advantages
- Precision Metering: The tapered needle and matched seat provide smooth, linear flow adjustment for accurate speed and bleed control in hydraulic circuits.
- Leak-Tight Cartridge Design: Engineered sealing geometry ensures minimal internal leakage and stable performance across the full pressure range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with hardened internal components for long service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original Vickers OEM standards, ensuring drop-in installation into existing manifold cavities.
- Lockable Setting: Integrated locknut maintains the adjusted flow position against vibration and system pressure fluctuations.
Typical Industrial Applications
The Vickers NV1-10-R-0 cartridge needle valve is widely used in plastic injection molding machines for mold clamping and injection speed control, metallurgical presses for ram speed regulation, CNC machine tools for feed and positioning circuits, and general industrial hydraulic power units requiring precise bleed-off or actuator speed adjustment. Its compact cartridge format makes it ideal for space-constrained manifold assemblies in mobile and stationary hydraulic systems.
PRODUCT IMAGES
Vickers NV1-10-R-0 / 565936 Cartridge Needle Valve
