Product Overview
The VICKERS V10HS01W04WB001C00ZAR000AZ31 is a high-performance sectional directional control valve engineered by Vickers (Eaton) for precise management of hydraulic fluid flow direction in demanding industrial circuits. This valve utilizes a robust spool-and-sleeve design actuated by a wet-armature solenoid, providing reliable shifting and positive sealing across multiple work sections. As a sectional valve, it allows flexible configuration of parallel or series circuits, making it ideal for mobile and industrial applications requiring coordinated control of multiple actuators. The V10 series is recognized for its high flow capacity, low pressure drop, and exceptional metering characteristics, ensuring smooth acceleration and deceleration of hydraulic loads.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Sectional Directional Control Valve (Solenoid Actuated) |
| Model Designation | V10HS01W04WB001C00ZAR000AZ31 |
| Operating Pressure | Up to 350 bar (5075 psi) rated, 420 bar (6090 psi) peak |
| Rated Flow | Up to 120 L/min (31.7 gpm) per section, depending on spool configuration |
| Spool Type | Closed-center, tandem, or open-center options (model-specific) |
| Actuation | Wet-armature solenoid, 12 VDC or 24 VDC (model-dependent), with manual override |
| Mounting & Connection | Subplate or manifold mounting per ISO 4401 / CETOP standards; SAE or BSPP port threads |
| Seal Material | Nitrile (Buna-N) or Viton for high-temperature compatibility |
| Filtration Requirement | ISO 4406 18/16/13 or better |
Engineering Features & Advantages
- Precision Spool Metering: Engineered spool lands and optimized flow passages deliver accurate proportional control, minimizing shock and improving actuator response in complex circuits.
- High-Flow Capacity: Large internal passages and efficient flow paths reduce pressure drop, enabling faster cycle times and energy savings in high-demand applications.
- Rugged Solenoid Construction: Wet-armature solenoids provide high force, long life, and environmental protection (IP65/IP67), ensuring reliable operation in harsh industrial environments.
- Sectional Flexibility: Modular design allows easy addition or removal of sections, simplifying system customization and maintenance without replacing the entire valve stack.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Precision-manufactured to original VICKERS specifications for direct replacement, minimising downtime and eliminating fitment issues.
Typical Industrial Applications
As a sectional valve, it allows flexible configuration of parallel or series circuits, making it ideal for mobile and industrial applications requiring coordinated control of multiple actuators.
PRODUCT IMAGES
VICKERS V10HS01W04WB001C00ZAR000AZ31 Sectional Directional Control Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine VICKERS V10HS01W04WB001C00ZAR000AZ31 Solenoid Directional Valve. This Germany-made 24V DC hydraulic component features a 4-way 3-position design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
