The WILO NL80/200-37/2 is a heavy-duty industrial centrifugal pump engineered for continuous duty in water supply, HVAC, and process engineering applications. It features a robust volute casing and a high-efficiency impeller designed to deliver reliable performance under demanding operating conditions.
WILO NL80/200-37/2 Technical Specifications
| Parameter | Value |
|---|---|
| Pump Type | Centrifugal, single-stage, end-suction |
| Nominal Flow Rate | Up to 200 m³/h |
| Maximum Head | 200 m |
| Motor Power | 37 kW |
| Voltage / Frequency | 400 V / 50 Hz (3-phase) |
| Speed | 2900 rpm |
| Connection Size | DN 80 (suction), DN 80 (discharge) |
| Max. Operating Pressure | 16 bar |
| Max. Fluid Temperature | 120 °C |
| Sealing | Mechanical seal |
| Mounting | Horizontal, foot-mounted |
| Materials | Cast iron casing, stainless steel shaft |
Key Engineering Features
- High-efficiency hydraulic design reduces energy consumption
- Robust cast iron construction for long service life
- Mechanical seal ensures reliable leakage-free operation
- Compact footprint and easy maintenance access
- Optimized impeller for stable performance across the curve
Industrial Applications
- Water supply and pressure boosting systems
- HVAC heating and cooling circuits
- Industrial process water circulation
- Irrigation and agricultural systems
- General industrial fluid transfer
For technical inquiries, dimensional drawings, or replacement support for WILO NL80/200-37/2, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
WILO NL80/200-37/2 Centrifugal Pump
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the WILO NL80/200-37/2 Centrifugal Pump. This precision-engineered industrial component delivers reliable performance and accurate operation for demanding industrial systems.
