Product Overview
The YUKEN DSG-01-3C2-A220-N1-51T is a high-performance solenoid operated directional control valve from YUKEN’s renowned DSG series, engineered for precise control of hydraulic fluid flow direction in industrial hydraulic systems. This direct-acting, spring-centered directional valve features a 3C2 spool configuration (three-position, four-way, tandem center) that provides reliable directional control of double-acting cylinders and bidirectional hydraulic motors. The valve is actuated by a single A220 AC solenoid (220V AC, 50/60 Hz) with a spring return mechanism, ensuring automatic return to the center position upon de-energization for fail-safe operation. The “N1” designation indicates a standard electrical connection with DIN plug compatibility, while the “51T” suffix denotes the specific design series and seal configuration. Manufactured to YUKEN’s exacting standards, this valve delivers exceptional response times, minimal pressure drop, and long service life, making it a preferred choice for demanding industrial applications requiring precise directional control.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Operated Directional Control Valve |
| Model Designation | DSG-01-3C2-A220-N1-51T |
| Valve Configuration | 3-Position, 4-Way (3C2 Spool Type) |
| Actuation Method | Single AC Solenoid with Spring Return |
| Solenoid Voltage | 220V AC, 50/60 Hz |
| Operating Pressure | Up to 315 bar (Rated), 350 bar (Max) |
| Rated Flow | Up to 63 L/min (Nominal) |
| Mounting & Connection | Subplate Mounting, ISO 4401-03 / CETOP 3 / NG6 Interface |
| Electrical Connection | DIN Plug Connector (N1 Type) |
| Seal Material | NBR (Buna-N) Standard, Viton Optional |
| Fluid Compatibility | Mineral-Based Hydraulic Oil, Phosphate Ester (with appropriate seals) |
Engineering Features & Advantages
- Precision Performance: The solenoid operated directional control valve delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original YUKEN standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 315 bar and flow rates up to 63 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
Manufactured to YUKEN’s exacting standards, this valve delivers exceptional response times, minimal pressure drop, and long service life, making it a preferred choice for demanding industrial applications requiring precise directional control.
PRODUCT IMAGES
YUKEN DSG-01-3C2-A220-N1-51T Solenoid Operated Directional Valve
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine YUKEN DSG-01-3C2-A220-N1-51T Solenoid Operated Directional Valve. This Japan-made 220V AC hydraulic component features a 3-position, 4-way design with spring return, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
