Product Overview
The YUKEN DSG-01-3C2-D24-N1-50 is a high-performance solenoid operated directional valve from YUKEN’s renowned DSG series, engineered to control the start, stop, and direction of hydraulic fluid flow in industrial hydraulic systems. This direct-acting, spring-centered directional control valve features a 3-position, 4-way (3C2) spool configuration, providing reliable and precise directional control for double-acting actuators, cylinders, and hydraulic motors. With a 24V DC solenoid coil and a compact NG6 (CETOP 3 / ISO 4401-03) mounting interface, this valve is designed for seamless integration into manifold and subplate-mounted hydraulic circuits. The DSG-01 series is widely recognized for its fast response, low pressure drop, and long service life, making it a preferred choice for demanding industrial applications requiring dependable directional flow control.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Operated Directional Valve |
| Model Designation | DSG-01-3C2-D24-N1-50 |
| Spool Type | 3C2 — 3-Position, 4-Way, Spring Centered |
| Solenoid Voltage | 24V DC (D24) |
| Mounting Interface | NG6 / CETOP 3 / ISO 4401-03 Subplate Mounting |
| Operating Pressure | Up to 315 bar (Rated Industrial Grade) |
| Rated Flow | Up to 63 L/min (Standard NG6 Rating) |
| Electrical Connection | DIN 43650 Standard Connector |
| Seal Type | N1 — Nitrile Rubber (NBR) Seals |
| Design Number | 50 Series |
Engineering Features & Advantages
- Precision Spool Control: The 3C2 spool configuration delivers accurate and repeatable directional flow control, ensuring precise actuator positioning and smooth operation in complex hydraulic circuits.
- Fast Solenoid Response: High-efficiency 24V DC solenoid coils provide rapid shifting and de-energization, minimizing cycle times and improving overall system productivity.
- Low Pressure Drop: Optimized internal flow passages reduce pressure losses across the valve, enhancing energy efficiency and reducing heat generation in the hydraulic system.
- Industrial Reliability: Designed for dependable long-term operation in demanding industrial environments, with quality bearings and sealing systems ensuring extended maintenance intervals.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original YUKEN standards, allowing straightforward retrofit into existing hydraulic systems without rework.
Typical Industrial Applications
The DSG-01 series is widely recognized for its fast response, low pressure drop, and long service life, making it a preferred choice for demanding industrial applications requiring dependable directional flow control.
PRODUCT IMAGES
YUKEN DSG-01-3C2-D24-N1-50 Solenoid Operated Directional Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine YUKEN DSG-01-3C2-D24-N1-50 Solenoid Directional Control Valve. This Japan-made 24V DC hydraulic component features a 3-position, spring-centered design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
