Product Overview
The YUKEN DSG-03-3C60-D24-N1-50 is a high-performance solenoid operated directional valve from YUKEN’s renowned DSG series, engineered to direct hydraulic flow with precision and reliability in demanding industrial circuits. Utilizing a wet-type AC/DC solenoid with a spring-centered, spring-offset spool design, this valve shifts a precision-ground spool within a hardened valve body to control the start, stop, and direction of hydraulic fluid flow. The “3C60” spool configuration provides a closed-center, tandem-type flow path, making it ideal for controlling double-acting cylinders and bidirectional hydraulic motors where load holding and precise directional control are essential. As a direct-acting, subplate-mounted valve, the DSG-03 series is a global industry standard for machine tool, press, and general industrial hydraulic systems requiring fast response, low pressure drop, and long service life.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Operated Directional Valve (Hydraulic Valve) |
| Model Designation | DSG-03-3C60-D24-N1-50 |
| Series / Size | DSG-03 (NG10 / CETOP 5 / ISO 4401-05) |
| Spool Type | 3C60 — Closed Center, Tandem Type, Spring Centered |
| Number of Positions | 3-Position, 4-Way |
| Solenoid Voltage | D24 — 24V DC Solenoid |
| Electrical Connection | N1 — DIN 43650 Connector (without indicator light) |
| Design Number | 50 Series |
| Operating Pressure | Up to 315 bar (Rated Industrial Grade) |
| Max. Flow Rate | Up to 100 L/min (NG10 nominal) |
| Mounting & Connection | Subplate Mounting, ISO 4401-05 / CETOP 5 Interface |
Engineering Features & Advantages
- Precision Performance: The solenoid operated directional valve (hydraulic valve) delivers precise, repeatable performance with low hysteresis and stable control across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Precision-manufactured to original YUKEN specifications for direct replacement, minimising downtime and eliminating fitment issues.
- Rated Capability: Rated for pressure ratings up to 315 bar and flow rates up to 100 L/min, supporting stable operation across the full working range.
Typical Industrial Applications
As a direct-acting, subplate-mounted valve, the DSG-03 series is a global industry standard for machine tool, press, and general industrial hydraulic systems requiring fast response, low pressure drop, and long service life.
PRODUCT IMAGES
YUKEN DSG-03-3C60-D24-N1-50 Solenoid Operated Directional Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine YUKEN DSG-03-3C60-D24-N1-50 Solenoid Operated Directional Valve. This Japan-made 24V DC hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
