Product Overview
The YUKEN DSHG-04-3C4-T-D24-N1-51T is a solenoid controlled pilot operated directional valve engineered by YUKEN, a globally recognized leader in hydraulic component manufacturing. This valve utilizes a two-stage design in which a small solenoid-actuated pilot valve controls the hydraulic pressure that shifts the main spool, enabling high flow capacity with minimal electrical power input. The DSHG series is designed for precise directional control of hydraulic actuators in demanding industrial circuits, providing reliable switching, low pressure drop, and rapid response times. With a 3C4 spool configuration and D24 (24V DC) solenoid, this valve is a direct-fit solution for a wide range of high-pressure hydraulic systems requiring dependable directional control.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Solenoid Controlled Pilot Operated Directional Valve |
| Model Designation | DSHG-04-3C4-T-D24-N1-51T |
| Spool Type | 3C4 — Three-position, four-way, closed center |
| Solenoid Voltage | D24 — 24V DC |
| Operating Pressure | Up to 315 bar (rated); pilot pressure required for main spool actuation |
| Nominal Flow Capacity | Up to 300 L/min (size 04 / NG10 interface) |
| Mounting & Connection | Subplate mounting, ISO 4401 / CETOP 5 (NG10) interface |
| Electrical Connection | N1 — DIN 43650 connector with indicator light |
| Design Number | 51T — Series 51 design |
Engineering Features & Advantages
- Pilot Operated Precision: The two-stage pilot operated design allows the small solenoid pilot valve to control main spool movement, delivering high flow capacity with low electrical power consumption and consistent, repeatable shifting performance.
- Low Pressure Drop: Optimized internal flow passages and spool geometry minimize pressure losses across the valve, improving overall system efficiency and reducing heat generation.
- Fast Response & Reliable Switching: The pilot-operated mechanism ensures rapid, positive spool actuation with minimal delay, critical for high-cycle industrial applications requiring precise directional control.
- Robust Solenoid Construction: The D24 (24V DC) solenoid is designed for continuous duty with high pull-in force, protected by a durable enclosure suitable for demanding industrial environments.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original YUKEN OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
With a 3C4 spool configuration and D24 (24V DC) solenoid, this valve is a direct-fit solution for a wide range of high-pressure hydraulic systems requiring dependable directional control.
PRODUCT IMAGES
YUKEN DSHG-04-3C4-T-D24-N1-51T Solenoid Controlled Pilot Operated Directional Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine YUKEN DSHG-04-3C4-T-D24-N1-51T Solenoid Directional Valve. This Japan-made 24V DC hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
