The YUKEN EFBG-10-500-C-17 is a heavy-duty industrial proportional valve engineered for precise electro-hydraulic control of pressure and flow in demanding hydraulic systems. It features a robust spool design with integrated pressure compensation, ensuring stable operation under varying load conditions.
YUKEN EFBG-10-500-C-17 Technical Specifications
| Parameter | Specification |
|---|---|
| Valve Type | Proportional Pressure/Flow Control Valve |
| Nominal Size | NG10 (CETOP 5) |
| Max. Operating Pressure | 315 bar |
| Max. Flow Rate | 500 L/min |
| Control Spool | Closed center, with position feedback |
| Actuation | Proportional solenoid, wet-pin type |
| Supply Voltage | 24 V DC (nominal) |
| Command Signal | 0 to ±10 V DC or 4-20 mA |
| Hysteresis | < 1% of rated signal |
| Mounting | Subplate, ISO 4401-05 / CETOP 5 |
| Fluid Temperature Range | -20 °C to +70 °C |
| Viscosity Range | 10 to 400 mm²/s |
| Filtration | ISO 4406 18/16/13 or better |
Key Engineering Features
- Integrated pressure compensation for stable flow control independent of load
- High-resolution proportional solenoid with low hysteresis
- Rugged spool and sleeve design for long service life
- Optional integrated electronics (C-17 variant) for simplified wiring
- Compatible with mineral oil and synthetic hydraulic fluids
Industrial Applications
- Injection molding machines
- Hydraulic presses
- Machine tools and CNC equipment
- Steel and metal processing lines
- Test stands and simulation systems
For technical inquiries, dimensional drawings, or replacement support for YUKEN EFBG-10-500-C-17, contact the Pro-Hydraulic engineering team.
PRODUCT IMAGES
YUKEN EFBG-10-500-C-17 Proportional Valve
