Product Overview
The YUKEN ELDFG-01EH-35-3C2L-XY-C-D-10 is a high-response proportional directional and flow control valve from YUKEN’s ELDFG series, engineered for precise electro-hydraulic control of actuator direction and velocity in demanding industrial circuits. This valve combines a high-performance proportional solenoid with a precision-machined spool and body assembly, delivering fast dynamic response, low hysteresis, and repeatable flow metering proportional to the electrical command signal. As a proportional control component, it regulates both the direction of flow and the magnitude of flow to the actuator, making it a core element in closed-loop and open-loop motion control systems where accurate speed, position, and force regulation are required. The ELDFG-01EH configuration is designed for direct integration into manifold or subplate-mounted hydraulic power units and is fully compatible with YUKEN’s proportional amplifier and control electronics for optimized system performance.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Proportional Directional and Flow Control Valve |
| Model Designation | ELDFG-01EH-35-3C2L-XY-C-D-10 |
| Manufacturer | YUKEN |
| Series | ELDFG High Response Proportional Series |
| Nominal Size | 01 (NG6 / CETOP 3 / ISO 4401-03 interface) |
| Spool Type | 3C2L — three-position, four-way, closed-center spool configuration |
| Actuation | Proportional solenoid with integrated position feedback (high-response design) |
| Operating Pressure | Standard industrial grade — up to 315 bar rated (dependent on port and spool configuration) |
| Rated Flow | Proportional flow control across full spool stroke; nominal flow matched to NG6 body size |
| Hysteresis & Repeatability | Low hysteresis, high repeatability for closed-loop position and velocity control |
| Mounting & Connection | Subplate / manifold mounting per ISO 4401-03 (CETOP 3) interface |
Engineering Features & Advantages
- Precision Performance: The integrated proportional solenoid with integrated position feedback (high-response design) ensures precise, repeatable control with low hysteresis and stable performance across the full working range.
- Industrial Reliability: Constructed for continuous duty with durable, corrosion-resistant materials and proven engineering for maximum system uptime.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original YUKEN standards, allowing straightforward retrofit into existing hydraulic systems without rework.
- Rated Capability: Rated for pressure ratings up to 315 bar, supporting stable operation across the full working range.
Typical Industrial Applications
As a proportional control component, it regulates both the direction of flow and the magnitude of flow to the actuator, making it a core element in closed-loop and open-loop motion control systems where accurate speed, position, and force regulation are required.
PRODUCT IMAGES
YUKEN ELDFG-01EH-35-3C2L-XY-C-D-10 High Response Proportional Directional and Flow Control Valve
