Product Overview
The ZETA GPCR08-3E6A1 is a high-performance hydraulic cartridge valve engineered by ZETA for precise directional control within compact manifold-based hydraulic circuits. Operating on a sliding spool principle, this screw-in cartridge valve directs, stops, and diverts hydraulic flow through a precision-machined spool and sleeve assembly, delivering fast, repeatable actuation for demanding industrial duty cycles. Its cavity-mounted design eliminates external leakage paths and reduces system footprint, making it an ideal solution for integrated hydraulic manifolds, mobile equipment, and high-cycle industrial machinery requiring dependable directional control at rated industrial pressures.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Cartridge Valve – Standard Directional Control Valve |
| Model Designation | GPCR08-3E6A1 |
| Manufacturer | ZETA |
| Operating Pressure | Standard Industrial Grade (Up to 350 bar rated) |
| Nominal Flow Capacity | NG08 / Size 08 cartridge cavity (approx. 30–40 L/min) |
| Actuation Type | Solenoid / Spool Actuated Directional Control |
| Mounting & Connection | Screw-in cartridge, Standard ISO 7784-8 / Manufacturer Cavity Interface |
| Sealing | NBR / FKM O-ring and back-up ring, manifold-seated |
| Fluid Compatibility | Mineral-based hydraulic oils (ISO VG 32–68), filtered to ISO 4406 cleanliness standards |
Engineering Features & Advantages
- Precision Spool Metering: Hardened, precision-ground spool and sleeve assembly ensures accurate flow direction control, minimal internal leakage, and consistent response across the full pressure range.
- Fast Actuation Response: Optimized spool geometry and spring return deliver rapid, repeatable shifting for high-cycle directional control applications.
- Compact Cartridge Architecture: Screw-in design integrates directly into custom manifolds, reducing piping, external leakage points, and overall system envelope.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with wear-resistant materials and robust sealing for long service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original OEM cavity and interface standards for drop-in servicing.
Typical Industrial Applications
The ZETA GPCR08-3E6A1 directional cartridge valve is widely deployed in plastic injection molding machines, metallurgical presses, CNC machine tool hydraulic power units, and construction and marine hydraulic systems where compact, high-cycle directional control
PRODUCT IMAGES
ZETA GPCR08-3E6A1 Hydraulic Cartridge Valve
⚡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine ZETA GPCR08-3E6A1 Solenoid Directional Control Valve. This Germany-made 24V DC hydraulic component features a spool-type design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
