Product Overview
The Fluke 718 300G Pressure Calibrator is a dedicated, handheld field calibration instrument engineered for the measurement, sourcing, and simulation of pressure and electrical signals in industrial process loops. Unlike a hydraulic pump or valve, this device is a precision diagnostic tool that combines a built-in electric pressure/vacuum pump with a high-accuracy pressure sensor and a milliamp (mA) loop calibrator. It is designed to verify, troubleshoot, and calibrate pressure transmitters, transducers, switches, and gauges. The “300G” designation indicates a pressure measurement range of up to 300 PSIG (pounds per square inch gauge), making it ideal for low-to-medium pressure instrumentation commonly found in process automation, HVAC, and fluid power control systems. Its integrated pump eliminates the need for external hand pumps, allowing technicians to generate pressure and vacuum directly at the test point for efficient, one-handed operation.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Pressure Calibrator (Motors, Sensors & Automation) |
| Model Designation | Fluke 718 300G |
| Pressure Range | 0 to 300 PSIG (0 to 20.7 bar) |
| Pressure Accuracy | ±0.025% of full scale (typical) |
| Electrical Measurement | 0 to 24 mA DC (loop calibrator function) |
| Internal Pump | Integrated manual pressure/vacuum pump |
| Mounting & Connection | 1/8 in NPT female pressure port; standard banana jacks for mA |
| Display | Digital LCD with backlight |
| Operating Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
Engineering Features & Advantages
- Integrated Pump & Sensor: Combines pressure generation and measurement in a single handheld unit, eliminating the need for separate hand pumps and reducing field calibration time.
- Dual Functionality: Simultaneously measures pressure and milliamp signals, enabling one-step calibration of pressure transmitters and I/P converters.
- High Accuracy & Stability: Precision sensor delivers ±0.025% full-scale accuracy, ensuring reliable calibration of critical process instrumentation.
- Rugged Industrial Design: Built to withstand harsh field environments with a protective holster and durable construction for continuous industrial use.
- Direct Fit Replacement: Compatible with standard 1/8 in NPT fittings and Fluke accessories, ensuring seamless integration into existing calibration workflows.
Typical Industrial Applications
This pressure calibrator
PRODUCT IMAGES
FLUKE 718 300G Pressure Calibrator
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine FLUKE 718 300G Pressure Calibrator. This US-made 300 psi pressure calibration tool features a built-in electric pump, delivering accurate, reliable pressure measurement for field calibration and industrial maintenance.
