Product Overview
The WHITE OMP X 32 (Part Number: 11185775) is a high-performance hydraulic orbital motor engineered by White Hydraulics (White Drive Products), a globally recognized brand in low-speed, high-torque (LSHT) hydraulic drive technology. This motor operates on the gerotor/orbital displacement principle, utilizing a precision-machined rotor and stator set to convert hydraulic pressure into smooth rotational torque. The OMP X series is specifically designed for medium-duty industrial applications requiring reliable starting torque, compact envelope size, and consistent performance across a wide speed range. With a nominal displacement of 32 cc/rev, this motor delivers dependable power transmission for auxiliary drives, conveyor systems, and mobile equipment where space and weight are critical constraints.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Orbital Motor (LSHT Gerotor Motor) |
| Model Designation | OMP X 32 / 11185775 |
| Displacement | 32 cc/rev (1.95 cu.in/rev) |
| Operating Pressure | Continuous: up to 175 bar (2537 psi) / Intermittent: up to 210 bar (3045 psi) |
| Peak Pressure | Up to 225 bar (3263 psi) for short duration |
| Torque Output | Continuous: approx. 80 Nm at 175 bar / Intermittent: approx. 96 Nm at 210 bar |
| Speed Range | Up to 775 RPM continuous (dependent on flow and load) |
| Mounting & Connection | Standard 2-bolt SAE A flange / 4-hole square flange; 1/2″ BSP or SAE ports (configuration dependent) |
| Shaft Type | Straight keyed shaft (standard) or splined options |
| Rotation | Bi-directional (reversible) |
Engineering Features & Advantages
- Precision Gerotor Performance: The advanced orbital rotor-stator geometry ensures high volumetric efficiency, smooth low-speed operation, and excellent starting torque characteristics under load.
- Compact & Lightweight Design: The OMP X series features a space-saving, lightweight construction ideal for mobile and auxiliary drive systems where minimizing weight and envelope is critical.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, with robust construction and wear-resistant internal components for extended service life.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original WHITE OEM standards, ensuring drop-in replacement without modification to existing manifolds or piping.
Typical Industrial Applications
With a nominal displacement of 32 cc/rev, this motor delivers dependable power transmission for auxiliary drives, conveyor systems, and mobile equipment where space and weight are critical constraints.
PRODUCT IMAGES
WHITE OMP X 32 / 11185775 Hydraulic Orbital Motor
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine WHITE OMP X 32 / 11185775 Hydraulic Orbital Motor. This Germany-made 32 cc/rev hydraulic component features a gerotor design, delivering leak-free, reliable fluid control for heavy-duty industrial systems.
