Product Overview
The WHITE OMR X 50 (Part Number: 11185537) is a high-performance hydraulic orbital motor engineered for demanding industrial drive applications. Manufactured to White Hydraulics’ exacting standards, this motor operates on the proven orbital (gerotor) principle, converting hydraulic fluid pressure into reliable rotary mechanical power. The OMR X series is renowned for its compact, robust construction and smooth, low-speed high-torque output, making it an ideal direct-drive solution for continuous-duty industrial machinery. With a nominal displacement of 50 cc/rev, this motor delivers consistent performance across a wide speed range without the need for complex gear reduction.
Technical Specifications
| Parameter | Specification / Feature |
|---|---|
| Component Type | Hydraulic Orbital Motor (Gerotor / Orbital Motor) |
| Model Designation | OMR X 50 / 11185537 |
| Nominal Displacement | 50 cc/rev (approx. 3.05 cu.in/rev) |
| Operating Pressure | Standard Industrial Grade (Up to 175 bar continuous / 210 bar intermittent) |
| Torque Output | High torque at low speed (approx. 120 Nm at 140 bar) |
| Speed Range | Smooth operation from 10 to 600 RPM |
| Mounting & Connection | Standard ISO / Manufacturer Interface (SAE 4-bolt flange, 1/2″ BSPP ports) |
| Shaft Type | Standard keyed cylindrical shaft (25 mm) |
Engineering Features & Advantages
- Precision Orbital Performance: The advanced gerotor (orbital) gear set provides exceptionally smooth rotation with minimal pressure ripple, ensuring quiet operation and extended service life in continuous-duty cycles.
- High Torque Density: Delivers substantial torque output directly at the shaft without auxiliary gearboxes, simplifying machine design and reducing maintenance points.
- Industrial Reliability: Built for continuous operation under severe industrial conditions, featuring a robust cast-iron housing and hardened internal components for resistance to shock loads and contamination.
- Direct Fit Replacement: Exact dimensional and functional compatibility with original White OMR X 50 and OEM part number 11185537, ensuring drop-in replacement without modification.
- Wide Speed Capability: Operates efficiently across a broad speed range, from low-speed high-torque indexing to moderate-speed conveying applications.
Typical Industrial Applications
This hydraulic orbital motor is ideally suited for heavy industrial scenarios including plastic injection molding machines (ejector and screw drive systems), metallurgical presses and manipulators, construction and marine hydraulics (winches, augers, and steering systems), and CNC machine tool tool-changers and rotary tables. Its robust design also excels in agricultural equipment, material handling conveyors, and mobile hydraulic drive circuits where
PRODUCT IMAGES
WHITE OMR X 50 / 11185537 Hydraulic Orbital Motor
âš¡ Emergency Plant Maintenance & Ready-to-Ship Notice:
- Authentic & Fully Tested: 100% bench tested for hydraulic response, pressure rating, and null-bias stability before dispatch.
- Fast Dispatch: In-stock units ready for same-day dispatch via DHL / FedEx Express directly to your plant.
- Pre-Shipment Verification: High-definition photos, video testing runs, and serial number verification provided prior to shipment.
- Peace of Mind: Covered by our 12-Month Replacement Warranty.
Shop the genuine WHITE OMR X 50 / 11185537 Hydraulic Motor. This Germany-made 50 cc/rev hydraulic component features a gerotor design, delivering leak-free, reliable fluid power for heavy-duty industrial systems.
